NTPsec

sam.ljay.org.uk

Report generated: Fri Sep 12 17:00:03 2025 UTC
Start Time: Thu Sep 4 17:00:01 2025 UTC
End Time: Fri Sep 12 17:00:01 2025 UTC
Report Period: 8.0 days

Top   Daily Stats   Weekly Stats

Local Clock Time/Frequency Offsets

local offset plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Time Offset -56.593 -29.916 -19.029 -0.663 18.820 29.513 62.745 37.849 59.429 10.921 -0.037 µs -3.962 12.15
Local Clock Frequency Offset 13.430 13.446 13.508 13.668 13.824 13.846 13.858 0.316 0.400 0.103 13.667 ppm 2.286e+06 3.011e+08

The time and frequency offsets between the ntpd calculated time and the local system clock. Showing frequency offset (red, in parts per million, scale on right) and the time offset (blue, in μs, scale on left). Quick changes in time offset will lead to larger frequency offsets.

These are fields 3 (time) and 4 (frequency) from the loopstats log file.



Local RMS Time Jitter

local jitter plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Time Jitter 0.360 0.515 0.723 8.684 16.890 19.997 30.323 16.167 19.482 5.403 8.255 µs 1.919 4.296

The RMS Jitter of the local clock offset. In other words, how fast the local clock offset is changing.

Lower is better. An ideal system would be a horizontal line at 0μs.

RMS jitter is field 5 in the loopstats log file.



Local RMS Frequency Jitter

local stability plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Frequency Jitter 0.032 0.073 0.132 0.588 1.113 1.420 1.989 0.981 1.347 0.317 0.587 ppb 3.626 9.391

The RMS Frequency Jitter (aka wander) of the local clock's frequency. In other words, how fast the local clock changes frequency.

Lower is better. An ideal clock would be a horizontal line at 0ppm.

RMS Frequency Jitter is field 6 in the loopstats log file.



Local Clock Time Offset Histogram

local offset histogram plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Offset -56.593 -29.916 -19.029 -0.663 18.820 29.513 62.745 37.849 59.429 10.921 -0.037 µs -3.962 12.15

The clock offsets of the local clock as a histogram.

The Local Clock Offset is field 3 from the loopstats log file.



Local Temperatures

local temps plot

Local temperatures. These will be site-specific depending upon what temperature sensors you collect data from. Temperature changes affect the local clock crystal frequency and stability. The math of how temperature changes frequency is complex, and also depends on crystal aging. So there is no easy way to correct for it in software. This is the single most important component of frequency drift.

The Local Temperatures are from field 3 from the tempstats log file.



Local Frequency/Temp

local freq temps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset 13.430 13.446 13.508 13.668 13.824 13.846 13.858 0.316 0.400 0.103 13.667 ppm 2.286e+06 3.011e+08
Temp LM0 43.000 43.000 43.000 44.000 45.000 46.000 46.000 2.000 3.000 0.698 44.304 °C
Temp LM1 21.000 22.000 23.000 25.000 27.000 28.000 33.000 4.000 6.000 1.316 25.245 °C
Temp LM2 36.000 36.000 36.000 37.000 38.000 38.000 41.000 2.000 2.000 0.798 37.145 °C
Temp LM3 36.000 36.000 36.000 38.000 38.000 39.000 41.000 2.000 3.000 0.709 37.488 °C
Temp LM4 35.000 35.000 35.000 36.000 37.000 38.000 40.000 2.000 3.000 0.685 36.355 °C
Temp LM5 27.800 27.800 27.800 27.800 27.800 27.800 27.800 0.000 0.000 0.000 27.800 °C
Temp LM6 29.800 29.800 29.800 29.800 29.800 29.800 29.800 0.000 0.000 0.000 29.800 °C
Temp LM7 33.000 34.000 34.000 36.000 38.000 39.000 42.000 4.000 5.000 1.151 36.209 °C
Temp LM8 33.000 34.000 34.000 36.000 38.000 39.000 42.000 4.000 5.000 1.149 36.215 °C
Temp LM9 31.000 32.000 32.000 34.000 35.000 36.000 39.000 3.000 4.000 0.899 33.672 °C
Temp ZONE0 29.800 29.800 29.800 29.800 29.800 29.800 29.800 0.000 0.000 0.000 29.800 °C
Temp ZONE1 33.000 34.000 34.000 36.000 38.000 39.000 42.000 4.000 5.000 1.147 36.174 °C
Temp ZONE2 27.800 27.800 27.800 27.800 27.800 27.800 27.800 0.000 0.000 0.000 27.800 °C

The frequency offsets and temperatures. Showing frequency offset (red, in parts per million, scale on right) and the temperatures.

These are field 4 (frequency) from the loopstats log file, and field 3 from the tempstats log file.



Local GPS

local gps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
nSats 4.000 6.000 7.000 8.000 10.000 11.000 11.000 3.000 5.000 0.993 8.412 nSat 438.7 3446
TDOP 0.530 0.590 0.640 0.910 1.510 2.160 5.610 0.870 1.570 0.347 0.978 15.66 100.6

Local GPS. The Time Dilution of Precision (TDOP) is plotted in blue. The number of visible satellites (nSat) is plotted in red.

TDOP is field 3, and nSats is field 4, from the gpsd log file. The gpsd log file is created by the ntploggps program.

TDOP is a dimensionless error factor. Smaller numbers are better. TDOP ranges from 1 (ideal), 2 to 5 (good), to greater than 20 (poor). Some GNSS receivers report TDOP less than one which is theoretically impossible.



Server Offsets

peer offsets plot

The offset of all refclocks and servers. This can be useful to see if offset changes are happening in a single clock or all clocks together.

Clock Offset is field 5 in the peerstats log file.



Refclock Offset 127.127.28.0 SHM(0)

peer offset 127.127.28.0 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Refclock Offset 127.127.28.0 SHM(0) -701.826 -673.652 -656.272 -616.746 -580.248 -563.900 -518.676 76.024 109.752 23.028 -617.336 ms -2.159e+04 6.027e+05

The offset of a local refclock in seconds. This is useful to see how the measured offset is behaving.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local serial GPS 200 ms; local PPS 20µs.

Clock Offset is field 5 in the peerstats log file.



Refclock Offset 127.127.28.1 SHM(1)

peer offset 127.127.28.1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Refclock Offset 127.127.28.1 SHM(1) -56.594 -29.917 -19.030 -0.664 18.821 29.514 62.746 37.851 59.431 10.922 -0.037 µs -3.962 12.15

The offset of a local refclock in seconds. This is useful to see how the measured offset is behaving.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local serial GPS 200 ms; local PPS 20µs.

Clock Offset is field 5 in the peerstats log file.



Server Offset 139.143.5.31

peer offset 139.143.5.31 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 139.143.5.31 -103.776 77.880 277.155 603.637 688.021 762.056 882.922 410.866 684.176 139.394 554.409 µs 33.83 119.3

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 193.67.79.202

peer offset 193.67.79.202 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 193.67.79.202 -432.557 -277.753 -83.627 255.124 343.644 401.752 599.253 427.271 679.505 142.976 204.740 µs -0.05713 3.543

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2001:8b0:0:23::205 (ntp2.aa.net.uk)

peer offset 2001:8b0:0:23::205 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2001:8b0:0:23::205 (ntp2.aa.net.uk) -0.587 -0.299 0.044 0.655 1.303 1.587 1.718 1.258 1.887 0.338 0.631 ms 3.409 10.14

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 81.187.26.174

peer offset 81.187.26.174 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 81.187.26.174 -761.098 -402.585 -178.422 156.589 250.734 340.237 431.204 429.156 742.822 146.384 104.540 µs -2.298 7.218

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Jitters

peer jitters plot

The RMS Jitter of all refclocks and servers. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Refclock RMS Jitter 127.127.28.0 SHM(0)

peer jitter 127.127.28.0 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Refclock RMS Jitter 127.127.28.0 SHM(0) 0.825 2.629 4.520 12.029 26.223 34.192 55.060 21.703 31.563 6.679 13.277 ms 5.033 15.91

The RMS Jitter of a local refclock. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Refclock RMS Jitter 127.127.28.1 SHM(1)

peer jitter 127.127.28.1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Refclock RMS Jitter 127.127.28.1 SHM(1) 0.130 0.285 0.496 7.589 27.211 37.082 69.148 26.715 36.797 9.168 9.567 µs 1.252 4.397

The RMS Jitter of a local refclock. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 139.143.5.31

peer jitter 139.143.5.31 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 139.143.5.31 0.008 0.015 0.021 0.059 0.498 3.126 38.763 0.477 3.111 2.200 0.325 ms 9.832 144.8

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 193.67.79.202

peer jitter 193.67.79.202 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 193.67.79.202 0.010 0.016 0.022 0.058 0.373 4.256 31.898 0.351 4.240 2.071 0.282 ms 9.379 134.4

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2001:8b0:0:23::205 (ntp2.aa.net.uk)

peer jitter 2001:8b0:0:23::205 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2001:8b0:0:23::205 (ntp2.aa.net.uk) 0.008 0.014 0.020 0.054 0.371 2.109 37.625 0.352 2.095 2.347 0.279 ms 10.02 144.6

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 81.187.26.174

peer jitter 81.187.26.174 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 81.187.26.174 0.006 0.014 0.020 0.059 0.376 0.762 38.486 0.355 0.748 1.240 0.172 ms 18.69 485.6

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Summary


Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset 13.430 13.446 13.508 13.668 13.824 13.846 13.858 0.316 0.400 0.103 13.667 ppm 2.286e+06 3.011e+08
Local Clock Time Offset -56.593 -29.916 -19.029 -0.663 18.820 29.513 62.745 37.849 59.429 10.921 -0.037 µs -3.962 12.15
Local RMS Frequency Jitter 0.032 0.073 0.132 0.588 1.113 1.420 1.989 0.981 1.347 0.317 0.587 ppb 3.626 9.391
Local RMS Time Jitter 0.360 0.515 0.723 8.684 16.890 19.997 30.323 16.167 19.482 5.403 8.255 µs 1.919 4.296
Refclock Offset 127.127.28.0 SHM(0) -701.826 -673.652 -656.272 -616.746 -580.248 -563.900 -518.676 76.024 109.752 23.028 -617.336 ms -2.159e+04 6.027e+05
Refclock Offset 127.127.28.1 SHM(1) -56.594 -29.917 -19.030 -0.664 18.821 29.514 62.746 37.851 59.431 10.922 -0.037 µs -3.962 12.15
Refclock RMS Jitter 127.127.28.0 SHM(0) 0.825 2.629 4.520 12.029 26.223 34.192 55.060 21.703 31.563 6.679 13.277 ms 5.033 15.91
Refclock RMS Jitter 127.127.28.1 SHM(1) 0.130 0.285 0.496 7.589 27.211 37.082 69.148 26.715 36.797 9.168 9.567 µs 1.252 4.397
Server Jitter 139.143.5.31 0.008 0.015 0.021 0.059 0.498 3.126 38.763 0.477 3.111 2.200 0.325 ms 9.832 144.8
Server Jitter 193.67.79.202 0.010 0.016 0.022 0.058 0.373 4.256 31.898 0.351 4.240 2.071 0.282 ms 9.379 134.4
Server Jitter 2001:8b0:0:23::205 (ntp2.aa.net.uk) 0.008 0.014 0.020 0.054 0.371 2.109 37.625 0.352 2.095 2.347 0.279 ms 10.02 144.6
Server Jitter 81.187.26.174 0.006 0.014 0.020 0.059 0.376 0.762 38.486 0.355 0.748 1.240 0.172 ms 18.69 485.6
Server Offset 139.143.5.31 -103.776 77.880 277.155 603.637 688.021 762.056 882.922 410.866 684.176 139.394 554.409 µs 33.83 119.3
Server Offset 193.67.79.202 -432.557 -277.753 -83.627 255.124 343.644 401.752 599.253 427.271 679.505 142.976 204.740 µs -0.05713 3.543
Server Offset 2001:8b0:0:23::205 (ntp2.aa.net.uk) -0.587 -0.299 0.044 0.655 1.303 1.587 1.718 1.258 1.887 0.338 0.631 ms 3.409 10.14
Server Offset 81.187.26.174 -761.098 -402.585 -178.422 156.589 250.734 340.237 431.204 429.156 742.822 146.384 104.540 µs -2.298 7.218
TDOP 0.530 0.590 0.640 0.910 1.510 2.160 5.610 0.870 1.570 0.347 0.978 15.66 100.6
Temp LM0 43.000 43.000 43.000 44.000 45.000 46.000 46.000 2.000 3.000 0.698 44.304 °C
Temp LM1 21.000 22.000 23.000 25.000 27.000 28.000 33.000 4.000 6.000 1.316 25.245 °C
Temp LM2 36.000 36.000 36.000 37.000 38.000 38.000 41.000 2.000 2.000 0.798 37.145 °C
Temp LM3 36.000 36.000 36.000 38.000 38.000 39.000 41.000 2.000 3.000 0.709 37.488 °C
Temp LM4 35.000 35.000 35.000 36.000 37.000 38.000 40.000 2.000 3.000 0.685 36.355 °C
Temp LM5 27.800 27.800 27.800 27.800 27.800 27.800 27.800 0.000 0.000 0.000 27.800 °C
Temp LM6 29.800 29.800 29.800 29.800 29.800 29.800 29.800 0.000 0.000 0.000 29.800 °C
Temp LM7 33.000 34.000 34.000 36.000 38.000 39.000 42.000 4.000 5.000 1.151 36.209 °C
Temp LM8 33.000 34.000 34.000 36.000 38.000 39.000 42.000 4.000 5.000 1.149 36.215 °C
Temp LM9 31.000 32.000 32.000 34.000 35.000 36.000 39.000 3.000 4.000 0.899 33.672 °C
Temp ZONE0 29.800 29.800 29.800 29.800 29.800 29.800 29.800 0.000 0.000 0.000 29.800 °C
Temp ZONE1 33.000 34.000 34.000 36.000 38.000 39.000 42.000 4.000 5.000 1.147 36.174 °C
Temp ZONE2 27.800 27.800 27.800 27.800 27.800 27.800 27.800 0.000 0.000 0.000 27.800 °C
nSats 4.000 6.000 7.000 8.000 10.000 11.000 11.000 3.000 5.000 0.993 8.412 nSat 438.7 3446
Summary as CSV file


Glossary:

frequency offset:
The difference between the ntpd calculated frequency and the local system clock frequency (usually in parts per million, ppm)
jitter, dispersion:
The short term change in a value. NTP measures Local Time Jitter, Refclock Jitter, and Server Jitter in seconds. Local Frequency Jitter is in ppm or ppb.
kurtosis, Kurt:
The kurtosis of a random variable X is the fourth standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of kurtosis. A normal distribution has a kurtosis of three. NIST describes a kurtosis over three as "heavy tailed" and one under three as "light tailed".
ms, millisecond:
One thousandth of a second = 0.001 seconds, 1e-3 seconds
mu, mean:
The arithmetic mean: the sum of all the values divided by the number of values. The formula for mu is: "mu = (∑xi) / N". Where xi denotes the data points and N is the number of data points.
ns, nanosecond:
One billionth of a second, also one thousandth of a microsecond, 0.000000001 seconds and 1e-9 seconds.
percentile:
The value below which a given percentage of values fall.
ppb, parts per billion:
Ratio between two values. These following are all the same: 1 ppb, one in one billion, 1/1,000,000,000, 0.000,000,001, 1e-9 and 0.000,000,1%
ppm, parts per million:
Ratio between two values. These following are all the same: 1 ppm, one in one million, 1/1,000,000, 0.000,001, and 0.000,1%
‰, parts per thousand:
Ratio between two values. These following are all the same: 1 ‰. one in one thousand, 1/1,000, 0.001, and 0.1%
refclock:
Reference clock, a local GPS module or other local source of time.
remote clock:
Any clock reached over the network, LAN or WAN. Also called a peer or server.
time offset:
The difference between the ntpd calculated time and the local system clock's time. Also called phase offset.
σ, sigma:
Sigma denotes the standard deviation (SD) and is centered on the arithmetic mean of the data set. The SD is simply the square root of the variance of the data set. Two sigma is simply twice the standard deviation. Three sigma is three times sigma. Smaller is better.
The formula for sigma is: "σ = √[ ∑(xi-mu)^2 / N ]". Where xi denotes the data points and N is the number of data points.
skewness, Skew:
The skewness of a random variable X is the third standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of skewness. Wikipedia describes it best: "The qualitative interpretation of the skew is complicated and unintuitive."
A normal distribution has a skewness of zero.
upstream clock:
Any server or reference clock used as a source of time.
µs, us, microsecond:
One millionth of a second, also one thousandth of a millisecond, 0.000,001 seconds, and 1e-6 seconds.



This page autogenerated by ntpviz, part of the NTPsec project
html 5    Valid CSS!
